• Dual hydraulic pump Terex TC20 TC22 splined PLP20.9-07S1-L/BC/20.6,3-LBE/-L1, 666000CJ

Hydraulic Pump Shaft 4000544, PLP20.9-07S1-L/BC/20.6,3-LBE/-L1, 666000CJ, 0250674P, 5100620006

€826.74
Tax included

FZ Hydraulics dual-section hydraulic gear pump featuring an involute splined drive shaft and counter-clockwise rotation.

Direct-fit replacement unit engineered for Terex TC20 and TC22 mini excavators.

Two displacement chambers divide hydraulic oil feed between boom articulation, slew ring motor, and crawler track drives.

OEM cross-references: PLP20.9-07S1-L/BC/20.6,3-LBE/-L1, 666000CJ, 0250674P, 5100620006.

Manufacturer: FZ Hydraulics
Reference number: 4000544, PLP20.9-07S1-L/BC/20.6,3-LBE/-L1, 666000CJ, 0250674P, 5100620006
Fits to:
mini koparki Terex TC22, TC20 w maszynach budowlanych

INSTALLMENTS
INSTALLMENTS
Buy now and pay within 30 days


12-Month Full Warranty



Same-Day Shipping



14-Day Return Policy

FZ Hydraulics tandem gear hydraulic pump with a splined input shaft, configured specifically for Terex TC20 and TC22 mini excavators.

Featuring two independent displacement chambers (9 cc and 6.3 cc/rev) on a single drive axis, it delivers separate fluid feeds to implement rams and travel motors, preventing control lag during coordinated trenching operations.

Technical specifications:

  • Brand: FZ Hydraulics

  • Component type: Dual-section external gear pump

  • Input shaft style: Involute spline profile
  • Rotation: Counter-clockwise / Left-hand (L)
  • Machinery compatibility: Terex TC20, Terex TC22 mini excavators
  • OEM cross-references: PLP20.9-07S1-L/BC/20.6,3-LBE/-L1, 666000CJ, 0250674P, 5100620006
  • Connected functions: Excavator boom/arm rams, bucket cylinder, track drive motors, swing drive, dozer blade

The compact body envelope allows straightforward installation in confined engine bays, while precision gear tooth geometry dampens hydraulic pulsations at high operating speeds.

Dedicated inter-stage seals isolate circuit pressures, ensuring smooth proportional response across variable oil operating temperatures.
