Hydraulic cylinder 2011753

Hydraulic cylinder 50/30x500 - custom-made execution

Hydraulic cylinder with a 50 mm piston diameter, 30 mm rod diameter, and 500 mm stroke, designed for use in construction and industrial hydraulic systems. Built for durability, precision, and reliable performance under heavy-duty conditions.

Each cylinder is manufactured on request, based on the provided technical drawing and customer specifications. The design ensures tight sealing, resistance to pressure peaks, and long operational life.

Technical specifications:

• Piston diameter: Ø50 mm

• Rod diameter: Ø30 mm

• Stroke: 500 mm

• Nominal pressure: 18 MPa

• Test pressure: 24 MPa

• Piston speed: up to 0.5 m/s

• Operating temperature: -20°C to +80°C

• Working fluid: hydraulic oil, viscosity 10–450 cSt

• Oil cleanliness: ≤100 µm

• Ports: G3/8"

• Mounting: eye Ø25.2 mm

Applications:

Used in:

• construction and industrial machinery,

• hydraulic lifting and pressing systems,

• custom hydraulic equipment.
