• Casappa flow divider 4x PLD20.8-/GD-N-C-I, 0199A104

Gear flow divider 4x PLD20.8-/GD-N-C-I, 0199A104 Casappa - original

€696.82
Tax included

Genuine 4-section Casappa POLARIS series rotary gear flow divider.

Engineered for precise, synchronous division of an input hydraulic fluid stream into four equal output lines, regardless of varying actuator loads (cylinders or hydraulic motors).

Manufacturer designation: 4x PLD20.8-/GD-N-C-I, order code: 0199A104.

Reference number: 4x PLD20.8-**/GD-N-C-I, 0199A104
Last items in stock

INSTALLMENTS
INSTALLMENTS
Buy now and pay within 30 days


12-Month Full Warranty



Same-Day Shipping



14-Day Return Policy

Genuine 4-section rotary gear flow divider manufactured in Italy by Casappa (POLARIS PLD20 series).

The unit consists of four mechanically coupled gear sections, delivering precise, uniform distribution of incoming hydraulic flow into four distinct delivery lines (or combining return flows) irrespective of system load variations.

Widely utilized in mobile agricultural equipment, lifting platforms, and industrial machinery where absolute actuator synchronization is critical.

Specification and technical parameters:

  • Manufacturer / Brand: Casappa (Italy) – genuine OEM product.

  • Component type: Rotary gear flow divider.

  • Number of sections: 4 sections (Group 20 / POLARIS series).

  • Factory code: 4x PLD20.8-/GD-N-C-I.

  • Order code: 0199A104.

  • Displacement: 8.26 cc/rev per section (PLD20.8 frame).

  • Operating application: Actuator synchronization (4 cylinders/motors), pressure intensification, leveling systems, and lifting structures.

The high-strength extruded aluminum alloy bodies combined with cast iron flanges ensure superior dimensional stability, cyclic pressure endurance, and effective heat dissipation.

Precision ground gears and DU dry-sliding bushings minimize internal flow bypass, providing high dividing accuracy and extended service life.
