• Hydraulic flow divider 1/2"-3/8" 24-40L 210 bar (01594594)

Hydraulic flow divider 1/2" - 3/8" (24-40 l/min, 210 bar) - 01594594

€115.74
Tax included

Precision hydraulic flow divider valve with 1/2" and 3/8" ports, designed for equal division of hydraulic oil flow in fluid power systems.

Flow range: 24–40 l/min (min. 25 l/min, max. 40 l/min), maximum working pressure: 210 bar.

Reference code: 01594594.

Manufacturer: FZ Hydraulics
Reference number: 01594594

INSTALLMENTS
INSTALLMENTS
Buy now and pay within 30 days


12-Month Full Warranty



Same-Day Shipping



14-Day Return Policy

Hydraulic flow divider valve engineered to accurately split an incoming fluid supply into two equal flow rates, regardless of pressure variations or differing loads on the actuators.

Ideal for synchronizing the movement of two hydraulic cylinders or motors powered by a single hydraulic source.

Specification and technical parameters:

  • Component type: Hydraulic spool-type flow divider

  • Threaded ports: 1/2" - 3/8"
  • Minimum flow rate: 25 l/min
  • Maximum flow rate: 40 l/min
  • Operating flow capacity: 24-40 l/min
  • Maximum operating pressure: 210 bar
  • Reference / part code: 01594594
  • Application: Cylinder synchronization, parallel hydraulic motor circuits, agricultural and industrial equipment

The rigid, heavy-duty housing provides structural durability under continuous operating pressure up to 210 bar.

Precision-machined internal spool components ensure accurate flow-splitting tolerances and minimal pressure drop, preventing uneven mechanical motion across synchronized equipment functions.
