Oil Cooler Thermostat M22x1.5 40°C - FZ Hydraulics (2010264)
FZ Hydraulics oil cooler thermostat with M22x1.5 thread, designed for automatic cooling system control in power hydraulics installations.
The component switches on at a temperature of 40°C, features an IP54 protection rating, and is rated for operation at a maximum pressure of up to 200 bar.
The main catalog number for the part is 2010264.
12-Month Full Warranty
Same-Day Shipping
14-Day Return Policy
Maintaining the proper temperature of working oil determines the stability of hydraulic system parameters, the preservation of optimal fluid viscosity, and the protection of components against overheating.
The presented FZ Hydraulics thermostat with an M22x1.5 connection thread is a precise thermal sensor designed to control cooler fans in industrial, agricultural, and construction machinery.
Technical data and operating specification:
-
40°C activation temperature: The component automatically initiates the cooling circuit once the oil reaches a temperature of 40°C, allowing the system to warm up quickly after startup while effectively preventing excessive temperature rise under load.
-
Pressure resistance up to 200 bar: The robust housing construction allows for safe and continuous operation in high-pressure installations.
-
IP54 protection rating: The sealed electrical connection housing guarantees resistance to dust and water splashes, enabling thermostat installation in severe environmental conditions.
-
Standard M22x1.5 thread: The metric thread ensures direct and trouble-free mounting in the majority of standard hydraulic oil coolers on the market.
-
Full compliance with catalog designations: FZ Hydraulics 2010264.
Choosing a thermostat from FZ Hydraulics ensures trouble-free thermal regulation of the installation and extends the service life of the pump, control valves, and seals throughout the machine.
This guarantees stable attachment operation and system safety under all working conditions.
-
Brand
-
ReferenceFZ Hydraulics 2010264
