Triple hydraulic pump FZ Hydraulics Case IH CS - milling shaft (0510765362, 69/565-386)
Efficient triple FZ Hydraulics pump featuring a splined shaft, engineered to supply working and auxiliary circuits in agricultural tractors.
Serves as a reliable replacement dedicated to Case IH CS series tractors (models CS 78, CS 86, CS 94, CS 80, CS 90, CS 100).
Replaces reference part numbers: 0510765362, 2560510765362, and 69/565-386.
12-Month Full Warranty
Same-Day Shipping
14-Day Return Policy
Triple hydraulic gear pump by FZ Hydraulics featuring a splined drive shaft, designed for demanding hydraulic circuits in Case IH agricultural tractors.
The three-section configuration provides simultaneous fluid delivery to the main equipment circuits, rear three-point hitch, auxiliary remote valves, and hydrostatic power steering.
Specification and technical parameters:
-
Brand: FZ Hydraulics.
-
Component type: Triple hydraulic gear pump (3-section).
-
Drive shaft type: Splined shaft, ensuring rigid mechanical engagement and lossless torque transmission.
-
Machine compatibility: Case IH tractors CS series (CS 78, CS 86, CS 94, CS 80, CS 90, CS 100).
-
Comparative / reference numbers: 0510765362, 2560510765362, 69/565-386.
-
Operating application: Main working hydraulics, hitch control, auxiliary valves, and hydrostatic steering.
The heavy-duty multi-section alloy body delivers exceptional dimensional stability under continuous peak operating pressure, effective thermal dissipation, and solid resistance to system pressure spikes.
Precision-machined internal pumping elements reduce volumetric bypass across all three sections, maintaining high efficiency across operational oil temperatures.
-
